Solid State Pulse Circuits : Second Edition

This volume extensively covers semiconductor pulse circuits, explaining circuit operation and analysis, and discusses in detail practical pulse circuit design methods. The first chapters explain the characteristics of pulse waveforms and RC circuits that must be understood before the study of pulse circuitry can commence. The operation of diodes, BJTs, FETs, and op-amps in switching circuits is covered next. This leads to the design and analysis of inverters, Schmitt trigger circuits, multivibrators, IC timer circuits, ramp generators, and function generators. Logic gates, logic circuits, and IC logic families are also studied. After individual circuits and gates are studied, they are used as building blocks to explain digital counting, digital frequency meters, ADCs and DACs, pulse modulation, time division multiplexing. Many design and analysis examples are offered throughout the text. The circuit design approach is a simple step-by-step procedure. Device data sheets in the appendices are referred to, and standard-value components are selected.
ASIN: 0835970574
VSKU: BVV.0835970574.G
Condition: Good
Author/Artist:Bell, David
Binding: Hardcover
Note: Any images shown are stock photographs and product may differ from what is shown.
Condition Notes: The item shows wear from consistent use, but it remains in good condition and works perfectly. All pages and cover are intact including the dust cover, if applicable . Spine may show signs of wear. Pages may include limited notes and highlighting. May NOT include discs, access code or other supplemental materials.
